Portable Electric Hydraulic Hole Puncher

The Glass Suction Cup features heavy duty rubber pads and a sturdy metal frame with a non slip handle. Designed for lifting moving and installing glass tile marble and other smooth flat surfaces it provides a secure grip and controlled handling.

Availability:

Quantity:



Inquire

Product Overview

Our portable electric hydraulic hole punch integrates high-power pure copper motor and reinforced four-cylinder hydraulic system, engineered for rugged industrial metal hole punching tasks. The ergonomic top handle brings comfortable handheld grip for mobile field operation; the matched foot pedal switch frees operator’s both hands to fix workpieces, greatly boosting punching accuracy and working efficiency.

The main body adopts high-strength alloy casting with anti-wear surface treatment to resist long-term hydraulic impact and rust damage. Multiple interchangeable punch dies are available for different hole diameters, compatible with various carbon steel, stainless steel, angle iron, U-channel steel and flat iron plates. Comparing with traditional bench drilling and manual hydraulic punch, this electric model features faster punching speed, lower labor intensity and stable continuous working performance without frequent shutdown from overheating.

Core Advantages

High Power Hydraulic Drive: Upgraded pure copper motor delivers stable output, four-cylinder hydraulic boosting structure ensures strong punching force for thick steel plates.
Foot Switch Hands-Free Control: External foot pedal separates power control from holding workpiece, improves punching precision and operational safety.
Wide Compatibility of Dies: Supporting customized punch molds from Φ6mm to Φ22.5mm, adaptable for different hole size requirements.
Portable Compact Design: Lightweight integral structure, easy to carry to construction sites, outdoor engineering workshops and temporary processing locations.
Continuous Heat-Resistant Performance: Optimized internal heat dissipation structure allows non-stop long-hour working under high-load operation.

Item	Parameter Detail
Rated Voltage	110V/220V 50/60Hz (Customizable per customer’s market)
Rated Motor Power	2300W~2800W
Maximum Punch Force	16 Ton Hydraulic Output
Max Punchable Plate Thickness	Carbon Steel ≤10mm; Stainless Steel ≤8mm
Available Punch Hole Diameter	Φ6mm / Φ9mm / Φ13mm / Φ17mm / Φ20.5mm / Φ22.5mm (Custom sizes acceptable)
Single Punch Time	1~3 Seconds per hole
Net Weight	13KG
Overall Dimension	510×140×330mm
Standard Configuration	Main machine + Foot Switch + 5 sets standard punch dies + User Manual
